Flat Sling 4 Legs - NBR 15637-1
The LEG PLANA 4-LEG NBR 15637-1 flat polyester lifting sling is manufactured in accordance with NBR 15637-1 with a safety factor of 7:1. Its main features are: ease of adjustment during the lifting operation, lightweight and high resistance.
Technical Specifications
| Width | Workload 0º à 45º | Workload 45º à 60º | Width | Workload 0º à 45º | Workload 45º à 60º | Width | Workload 0º à 45º | Workload 45º à 60º | |
|---|---|---|---|---|---|---|---|---|---|
| Color | Camada Dupla | 4 Pernas Camada Dupla | 4 Pernas Camada Dupla | Camada Tripla | 4 Pernas Camada Tripla | 4 Pernas Camada Tripla | Camada Quádrupla | 4 Pernas Camada Quádrupla | 4 Pernas Camada Quádrupla |
| Purple | 30mm | 2.100kg | 1.500kg | - | - | - | - | - | - |
| Green | 60mm | 4.200kg | 3.000kg | - | - | - | - | - | - |
| Yellow | 90mm | 6.300kg | 4.500kg | 60mm | 6.300kg | 4.500kg | - | - | - |
| Gray | 120mm | 8.400kg | 6.000kg | 90mm | 8.400kg | 6.000kg | 60mm | 8.400kg | 6.000kg |
| Red | 150mm | 10.500kg | 7.500kg | - | - | - | 75mm | 10.500kg | 7.500kg |
| Brown | - | - | - | 120mm | 12.600kg | 9.000kg | 90mm | 12.600kg | 9.000kg |
| Blue | - | - | - | - | - | - | 120mm | 16.800kg | 12.000kg |
| Orange | - | - | - | - | - | - | 150mm | 21.000kg | 15.000kg |
